SKU: EAD10
The EAD10 acoustic electronic drum module instantly transforms your acoustic drum kit into a powerful digital/electronic hybrid with sampled sounds and studio quality digital effects. It allows you to play and record your acoustic drums along with your favorite artists from your music library or from tracks from your friends and share them digitally.
With the free iOS app you can shoot, edit and upload videos of your drum performances.
The EAD10 enhances every aspect of your drumming – the way you practice, record and perform live and makes your acoustic drums do more.
Bring Your Groove
The EAD10 electronic acoustic drum module enhances the way you practice, record and perform with your acoustic drums and free your musical creativity.
Easy setup lets you pop on your headphones and instantly hear studio quality sound (including effects and triggered samples) with Scenes designed to match a wide variety of different music.
It's simple to record high quality audio to the module, USB flash drive or computer and then share your work with bandmates and friends. The free iOS app allows you to create stunning audio and video and easily share it directly from your mobile device.
Just attach the EAD10 sensor to your bass drum and you've created a complete hybrid system with a kick trigger and a stereo microphone.
The EAD10 has 50 preset and 200 user Scenes that customize your drum sound and allow you to connect triggers and drum pads to augment your setup.
Pick a song from your music library and the app’s tempo detection lets you add a click, change the tempo and select sections to repeat. It’s drum practice made perfect.
You can shoot, mix, edit, and upload your original music videos directly from the free iOS app.
Size/Weight (Trigger Module) |
||
Dimensions |
Width |
260 mm (main unit), 76 mm (sensor unit) |
Height |
63 mm (main unit), 88 mm (sensor unit) |
|
Depth |
138 mm (main unit), 78 mm (sensor unit) |
|
Weight |
Weight |
654 g (main unit), 464 g (sensor unit) |
Tone generator |
||
Scenes |
Preset: 50 User: 200 |
|
Reverb |
11 |
|
Effects |
Mic: 21, Trigger: 10 |
|
Trigger Sounds |
Tone generator |
AWM2 |
Maximum polyphony |
64 |
|
Voices |
757 |
|
Recorder |
||
Recording time |
Internal memory |
Approx. 1 min 30 sec |
USB flash drive |
Approx. 30 min/file |
|
Recording Format |
Record/playback |
WAV (44.1 kHz, 16 bit, stereo) |
Audio Files |
||
Import limit |
Up to 100 |
|
Playback sample format |
44.1 kHz |
|
Wave memory |
32 MB |
|
Maximum loadable sample size |
1 mono sample: 1.75 MB, 1 stereo sample: 3.5 MB |
|
sample format |
WAV (16 bit) |
Click-track |
||
Tempo |
30−300 BPM, tap tempo function |
|
Time signatures |
1/4 to 16/4, 1/8 to 16/8, 1/16 to 16/16 |
|
Subdivisions |
Accents, quarter notes, eighth notes, sixteenth notes, and eighth-note triplets |
Connectors |
||
Connectors |
DC IN (12 V), PHONES (standard stereo phone), AUX IN (stereo mini), OUTPUT L/MONO, R (standard mono phone), USB TO DEVICE, USB TO HOST |
|
Sensor Unit |
For Trigger sensor |
A (standard stereo phone) |
For Mic sensor |
B (standard stereo phone) |
|
Trigger input |
Stereo (L: trigger, R:trigger) |
1 KICK/2 (also serves as A), 3 SNARE/4 (standard stereo phone) |
Three-zone (L: trigger, R: rim switch) |
5, 6 (standard stereo phone) |
Functions |
||
Functions |
Trigger sensitivity adjustment, USB audio/MIDI, headphone EQ, metronome, auto power off |
Foot Pedal |
FOOT SW (standard stereo phone) |
|
Sensor outputs |
For Trigger sensor |
A (standard phone) |
For Mic sensor |
B (standard stereo phone) |
|
Sensor Types |
||
Microphone |
High SPL mic × 2 |
|
Trigger |
Exclusive for bass drum × 1 |
Other |
||
Included accessories |
Owner’s manual, PA-150 (or an equivalent recommended by Yamaha), module holder, module holder wing bolts (× 2), connector cables (1 pair), cable bands (× 3), adhesive cushions (× 2) |
