Ibanez Prestige AZ2204NW Electric Guitar

SKU: 6043362

$2,998 RRP $3,999
Finish: Mint Green
  • Ibanez Prestige AZ Series Guitar
  • Made In Japan
  • Adaptable design suitable for everything from blues to metal
  • Oval C S-Tech roasted maple neck
  • Compound radius fingerboard  with Roasted Maple fingerboard
  • 24 jumbo stainless steel frets
  • Seymour Duncan® Fortuna SSH pickups w/dyna-MIX9 switching system
  • Gotoh Magnum Lock w/height adjustable posts
  • Gotoh T1720B tremolo bridge

There are three principles behind the Ibanez Prestige line: Precision, Performance, and Playability. Prestige combines high-tech manufacturing techniques with old-world Japanese craftsmanship, in order to achieve true innovation in design and construction. The series incorporates ideas and suggestions from musicians from around the world as the cornerstones of the Prestige production process.

Taking adaptability to new extremes, the AZ series has established itself and carved out a place that spans everything from the warmest blues licks, to the most intense, shred-heavy metal riffs. Carrying this ethos forward, the AZ line embodies time-tested Ibanez innovation and player-focused features like a smooth, oval neck grip, a well-balanced asymmetrical body shape, and the neck heel allowing for unrivaled playability.

Features

Rosewood fretboard

Rosewood provides a well-balanced solid tone with a focused mid range.

dyna-MIX9 switching system with Alter Switch

dyna-MIX9 switching system with Alter Switch

The dyna-MIX 9 offers nine sound variations and can switch between humbucker and single coil modes with just a flick of the mini switch. One mode even simulates a humbucking sound from the combination of two single coil pickups.

Compound Radius Fretboard (228mm to 305mm)

Compound Radius Fretboard (228mm to 305mm)

Offering the best of both worlds, the digitized compound radius fretboard of the AZ-N is built to enhance both smooth chording and lead work in the upper register.

5 tremolo springs

5 tremolo springs

Five tremolo springs allow string vibration to be more efficiently transferred to the guitar body.

Non-recessed bridge cavity

Non-recessed bridge cavity

While the AZ series features a recessed bridge cavity for fluid and dynamic tremolo action, this model has non-recessed bridge cavity. The direct contact between bridge plate and the guitar body provides better resonance and helps facilitate subtle nuances in playing dynamics.

Seymour Duncan® Fortuna™ S-S-H pickups

Seymour Duncan® Fortuna™ S-S-H pickups

Seymour Duncan® Fortuna™ Pickups feature a moderate output and natural clean voicing which accurately reflect subtle playing nuances. From treble to bass, the overall tonal balance is evenly adjusted and works well with various effect pedals.

Gotoh® T1702B tremolo bridge

Gotoh® T1702B tremolo bridge

The T1702B tremolo bridge provides quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm. The tremolo block and saddles are made of brass, facilitating better overall resonance.

Oval C S-TECH WOOD Roasted Maple neck

Oval C S-TECH WOOD Roasted Maple neck

The S-TECH special roasted treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes. The neck is sealed with an oil finish which helps make it feel similar to a well-played guitar neck.

Ergonomic rear body contour

Ergonomic rear body contour

A shallow body back contour and a big forearm contour make the guitar body fit the player naturally, thus increasing playing comfort. The AZ body has a deep waist and different radii on each body edge curve, making it easier to play in both standing or sitting positions.

Gotoh Magnum Lock machine heads w/H.A.P.(Height Adjustable Post)

Gotoh® Magnum Lock machine heads w/H.A.P.(Height Adjustable Post)

GOTOH® MAGNUM LOCK® machine heads have an established reputation for tuning stability. Its H. A. P® (Height Adjustable Post). system allows for the adjustment of string posts for the appropriate tension of each string.

Luminlay side dot inlays

Luminlay side dot inlays

The Luminlay side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

Super All Access Neck Joint

Super All Access Neck Joint

The Super All Access Neck Joint increases playability and allows for easy access to the higher frets.

SWITCHING SYSTEM

AZ2204NW's Switching system diagram


When the alter switch is in neck position, two hum tap mode is on. When the alter switch is in bridge position, two hum tap mode is off. Two hum tap mode means the neck and middle pickups are wired in series and functioning as a humbucker. When two hum tap mode is off and the pickup selector switch is in neck position, neck pickup is selected. When the switch is in between neck and center position, neck and center pickups are selected. When the switch is in center position, center position is selected. When the switch is in between center and bridge position, center pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected. When two hum tap mode is on and the pickup selector switch is in neck position, the neck and center pickups are selected and they are in series. When the switch is in between neck and center position the neck pickup and bridge side of the bridge pickup are selected. When the switch is in center position, neck, center, and bridge pickups are selected; the neck and center pickups are in series mode. When the switch is in between center and bridge position, the neck side of the bridge pickup is selected. When the switch is in bridge position, the bridge pickup is selected.

CONTROLS

AZ2204NW's control diagram


With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the knee cutout is the five-way pickup selector switch. Closest to the end of the body is the tone knob. The volume knob is located right above the five-way pickup selector switch. Between the volume and tone knobs is the alter switch.

OTHER FEATURES

Luminlay side dots

dyna-MIX9 switching system w/Alter Switch

Gotoh® Magnum Lock machine heads w/H.A.P.

Hardshell case included

Neck type AZ Oval C S-TECH WOOD  Roasted Maple neck

Top/back/body Alder body

Fretboard Rosewood fretboard Mother of Pearl dot inlay

Frets 22 Jumbo Stainless Steel frets/Prestige fret edge treatment

Bridge Gotoh® T1702B tremolo bridge

String Spacing 10.5mm

Neck Pickup Seymour Duncan® Fortuna™ (S) neck pickup Passive/Alnico

Middle Pickup Seymour Duncan® Fortuna™ (S) middle pickup Passive/Alnico

Bridge Pickup Seymour Duncan® Fortuna™ (H) middle pickup Passive/Alnico

Nut Bone

Factory Tuning 1E, 2B, 3G, 4D, 5A, 6E

String Gauge .010/.013/.017/.026/.036/.046

Hardware Colour Chrome

NECK DIMENSIONS

Scale: 648mm/25.5"

Nut Width: 42mm

22nd Fret Width: 56.4mm

1st Fret Thickness: 20.5mm

12th Fret Thickness: 22.5mm

Radius: 305mm (12")
